Details
WITH Oil Cooler (8 Plate on 11" Centers)
OE Style Radiator with Plastic Tanks / Aluminum Core
May require use of lower mount bracket from original radiator.
OVERALL HEIGHT: 24 7/8"
OVERALL WIDTH: 18"
OVERLL DEPTH: 3 1/2"
CORE HEIGHT: 19 3/4"
CORE WIDTH: 17"
CORE DEPTH: 2"
INLET: 34mm (1 5/16")
OUTLET: 34mm (1 5/16")
FINS PER INCH: 12 - V Fin
FILL NECK: 32mm
OIL COOLER: 8 Plate - 11" CTRS
CAP: Use RW0021-6 Radiator Cap
12-Month Warranty*
OE Style Radiator with Plastic Tanks / Aluminum Core
May require use of lower mount bracket from original radiator.
OVERALL HEIGHT: 24 7/8"
OVERALL WIDTH: 18"
OVERLL DEPTH: 3 1/2"
CORE HEIGHT: 19 3/4"
CORE WIDTH: 17"
CORE DEPTH: 2"
INLET: 34mm (1 5/16")
OUTLET: 34mm (1 5/16")
FINS PER INCH: 12 - V Fin
FILL NECK: 32mm
OIL COOLER: 8 Plate - 11" CTRS
CAP: Use RW0021-6 Radiator Cap
12-Month Warranty*
OEM Part Numbers: 16410U217071, 16410U217171
Notes:
For Square Wave style core, see part no: SC-246325
For Feedlot style core, see part no: SC-246130
Click Here for description of different style cores.
