Radiator for Ford F Series Super Duty
F250, F350, F450 & F550 w/ 6.7L Diesel Engine
Years: 2011 - 2017
Main Radiator - See Notes below.
For Secondary Radiator, see part no: CR13339
OE Style Radiator with Plastic Tanks / Aluminum Core
CORE HEIGHT: 27 3/4"
CORE WIDTH: 38 3/8"
DEPTH: 1 5/8"
INLET: 2 1/4" - Upper Left
OUTLET: 2 1/4" - Lower Right
OIL COOLER: None
12-Month Warranty*
F250, F350, F450 & F550 w/ 6.7L Diesel Engine
Years: 2011 - 2017
Main Radiator - See Notes below.
For Secondary Radiator, see part no: CR13339
OE Style Radiator with Plastic Tanks / Aluminum Core
CORE HEIGHT: 27 3/4"
CORE WIDTH: 38 3/8"
DEPTH: 1 5/8"
INLET: 2 1/4" - Upper Left
OUTLET: 2 1/4" - Lower Right
OIL COOLER: None
12-Month Warranty*
OEM Part Numbers: BC3Z8005E, BC3Z8005K
Notes:
**This is the Main Radiator (located on the Engine Side of the Radiator Support).**
For 6.7L Models, which have 2 separate cooling systems. Each with its own radiator.
• Internally reinforced end tubes with bridge clips
• Added ribs in weak spots on the tank
• Extra strong integrated mounting points
• Tank to header attachment is strengthened by a heavy gauge steel crimp versus aluminum on the OEM
• Core has strong, heavy duty tubes and more fins per inch than OEM
Best Quality & Price - Satisfaction Guarantee
At Superior, we build and supply only the highest quality radiators with heavy duty components for superior quality, maximum heat rejection and long life durability.
We want your business and will go the distance to prove that our radiators and service are superior to others in the industry.
Please call us at 1-800-578-8416 and we will do our best to beat or match another price or quote you find.
Or, fill out the form below and we will contact you.
