**All Aluminum Radiator - Aluminum Tanks & Core**
Others supply the cheaper version with Plastic Tanks.
Know the superior quality you are paying for.
Note: This Radiator has a heater hose connection on the outlet tank above the oil cooler fittings and a 3/8 port on the inlet tank below connection. It also has a 1 1/4" connection on the grill side of the outlet tank.
Fits Ford Chassis Motorhomes, 7.3L & 7.5L 8Cyl Engines, 1991 to 1997. Including Winnebago Warrior
CORE HEIGHT: 24 1/4"
CORE WIDTH: 23 5/8"
DEPTH: 1 7/16"
INLET: 1 3/4" - Upper Right
OUTLET: 1 3/4" - Lower Left
OIL COOLER: 1/4 -18 NPT x 11 3/4" Centers
Years: 1991, 1992, 1993, 1994, 1995, 1996, 1997
12-Month Warranty*
Others supply the cheaper version with Plastic Tanks.
Know the superior quality you are paying for.
Note: This Radiator has a heater hose connection on the outlet tank above the oil cooler fittings and a 3/8 port on the inlet tank below connection. It also has a 1 1/4" connection on the grill side of the outlet tank.
Fits Ford Chassis Motorhomes, 7.3L & 7.5L 8Cyl Engines, 1991 to 1997. Including Winnebago Warrior
CORE HEIGHT: 24 1/4"
CORE WIDTH: 23 5/8"
DEPTH: 1 7/16"
INLET: 1 3/4" - Upper Right
OUTLET: 1 3/4" - Lower Left
OIL COOLER: 1/4 -18 NPT x 11 3/4" Centers
Years: 1991, 1992, 1993, 1994, 1995, 1996, 1997
12-Month Warranty*
OEM Part Numbers:
F3TZ8005C, F3TD8005AA, E9TD8005DB, E9TO8005DB, F5TD8005AA, F3TZ-8005-C, 236006, SCSI-236006, 238784
Additional Industry Part Numbers:
CR6006, 556006, TR9476, BTC8800, BT8800, FOR97, FLX000160, 1006026, 310022, 310022AT, 310022ST
